Запчасти Case 115CL (151) - No Description Provided

P228842

COLLAR

1шт.

P236967

SPECIAL MAT. SEAL

SPRING WASHER

1шт.

P240344

HOUSING

1шт.

P947609

PIPE

19 x 27

2шт.

P32657

SCREW

/BOLT, M10 x 60

2шт.

P126011

PIPE CLAMP

2шт.

P34814

WASHER

2шт.

100016

NUT,M10 x 1.5, Cl 8

2шт.

P33865

SCREW

/BOLT, M20 x 70

10шт.

P37551

UNION

2шт.

P35050

WASHER

10шт.

P34171

NUT

10шт.

P34224

NUT

10шт.

P137086

FITTING

CONNECTION

4шт.

P30054

BANJO BOLT

FEMALE SCREW

4шт.

P30402

O-RING

4шт.

P137087

FITTING

4шт.

P30402

O-RING

4шт.

P37077

ELBOW-CONNECTION

ELBOW CONNECTION

4шт.

P31993

HOSE

8 x 13

4шт.

P126740

1шт.

P34812

WASHER

4шт.

P32644

SCREW,Hex, M8 x 16

/BOLT, M8 x 16

4шт.

P443310

SHIN

BRACKET

1шт.

P34914

RUBBER WASHER

SPRING WASHER, 23 x 12.2 x 1.25

32шт.

P429813

SCREW,POINTED

VALVE

2шт.

P130837

SEAT

2шт.

P30402

O-RING

4шт.

P30054

BANJO BOLT

FEMALE SCREW

2шт.

P429814

GUIDE

2шт.

P30311

O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro

SEAL, 2.62 x 13.94-80

2шт.

P45285

WASHER

2шт.

P130838

CAP

COVER

2шт.

P32831

SCREW

/BOLT, M10 x 18

2шт.

P34563

NUT

2шт.

P38976

REDUCER

1шт.

P1240311

HOUSING

1шт.

P30441

O-RING

3 x 190

1шт.

P32943

SCREW

/BOLT, M12 x 35

2шт.

P34816

WASHER

2шт.

P143716

MOTOR

1шт.

P130455

O-RING,0.103" Thk x 3.237" ID, -152, Cl 5, 75 Duro

SEAL, 2.62 x 82.22-80

1шт.

P939305

PINION

1шт.

P32939

SCREW

/BOLT, M10 x 90

6шт.

P938902

KIT

ASSY

1шт.

P36339

RING, SNAP

LOCKING RING

1шт.

P36256

RING, SNAP

LOCKING RING

1шт.

P39619

BEARING

1шт.

P827814

SHAFT

1шт.

P34809

WASHER

6шт.

86508568

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8

BOLT, Hex, M6 x 16, Cl 8.8, Full Thd

6шт.

P240345

BOX

1шт.

P36321

SNAP RING

LOCKING RING

1шт.

P28429

COMPOSITE SEAL

METAL PLASTICS

2шт.

P37474

PLUG

2шт.

P35748

SPLIT PIN/SAFETY PIN

SPLIT PIN, 6 x 45

6шт.

P35774

SPLIT PIN/SAFETY PIN

SPLIT PIN/SAFET, 10 x 40

6шт.

P35774

SPLIT PIN/SAFETY PIN

SPLIT PIN/SAFET, 10 x 40

6шт.

P35748

SPLIT PIN/SAFETY PIN

SPLIT PIN, 6 x 45

6шт.

P246026

OIL SEAL

SEAL RING, 90 x 70 x 10

2шт.

P139640

BEARING

1шт.

P3446006

OIL SEAL

SEAL RING, 72 x 54 x 10

1шт.

P1830173

BOX

1шт.
