Запчасти Case 115CL (099) - NO DESCRIPTION PROVIDED

P2537736

ASSEMBLY

ASSY

1шт.

P34921

RUBBER WASHER

SPRING WASHER, 28 x 14.2 x 2.2

21шт.

P33085

SCREW

/BOLT, M16 x 40

1шт.

P34564

NUT

1шт.

P130867

CAP

COVER

1шт.

P1543697

SHOCK ABSORBER

1шт.

PN27B01

1шт.

P1127736

THREADED ROD

ASSEMBLING ROD, M18 x 80

4шт.

825-1418

NUT,M18, Cl 8

4шт.

P30460

O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro

SEAL, 2.62 x 25.07-80

1шт.

P29855

TAPPET

PUSHER

1шт.

P45281

SEAL

41 x 38 x 3

1шт.

P532993

SCREW

/BOLT, M20 x 75

6шт.

P1127737

THREADED ROD

ASSEMBLING ROD, M18 x 150

12шт.

825-1418

NUT,M18, Cl 8

12шт.

P34921

RUBBER WASHER

SPRING WASHER, 28 x 14.2 x 2.2

21шт.

P2537736

ASSEMBLY

ASSY

1шт.

P1130447

O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro

SEAL, 3.53 x 31.34-80

2шт.

P945258

BACK-UP RING

BUSHING

2шт.

P30318

O-RING

SEAL, 3.6 x 23

1шт.

P2037743

CAP

COVER

3шт.

P730040

BLEEDER UNIT

6шт.

P30437

O-RING

2.5 x 44

3шт.

P737441

PLUG

M39 x 2

3шт.

P1643623

DISTRIBUTOR

SELECTOR BLOCK

3шт.

P45281

SEAL

41 x 38 x 3

1шт.

P30318

O-RING

SEAL, 3.6 x 23

1шт.

P30308

SEAL,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro

2.7 x 8.9

1шт.

P1643613

ELEMENT

1шт.

P1643610

ELEMENT

1шт.

P30318

O-RING

SEAL, 3.6 x 23

1шт.

P834589

NUT, M24 x 1.5

1шт.

P834590

NUT, M24 x 1.5

1шт.

P2537736

ASSEMBLY

ASSY

4шт.

P34921

RUBBER WASHER

SPRING WASHER, 28 x 14.2 x 2.2

84шт.

P33085

SCREW

/BOLT, M16 x 40

4шт.

P34564

NUT

4шт.

P130867

CAP

COVER

4шт.

P1543696

SHOCK ABSORBER

2шт.

P5130110

CUPEL

3шт.

P35754

SPLIT PIN/SAFETY PIN

SPLIT PIN, 10 x 15

6шт.

P945258

BACK-UP RING

BUSHING

6шт.

P1130447

O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro

SEAL, 3.53 x 31.34-80

6шт.

P929914

VALVE POPPET

VALVE

3шт.

P1038179

COMPRESSION SPRING

COMPRESSION SPR

3шт.

P545228

SEAL

32 x 32 x 2

3шт.

P827895

BLANK-OFF PLUG

3шт.

P30460

O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro

SEAL, 2.62 x 25.07-80

4шт.

P29855

TAPPET

PUSHER

4шт.

P45281

SEAL

41 x 38 x 3

4шт.

P1229860

END FITTING

3шт.

P5130110

CUPEL

3шт.

P1338193

COMPRESSION SPRING

COMPRESSION SPR

3шт.

P1338194

COMPRESSION SPRING

COMPRESSION SPR

3шт.

P230419

O-RING

SEAL, 2.62 x 12.37-80

1шт.

P35754

SPLIT PIN/SAFETY PIN

SPLIT PIN, 10 x 15

2шт.

P138187

COMPRESSION SPRING

COMPRESSION SPR

1шт.

P30437

O-RING

2.5 x 44

1шт.

P2037739

SPACER

1шт.

P3028776

1шт.

P1237579

UNION

1шт.

P1443629

SELECTOR

1шт.

P2249628

SEAL PACKAGE

1шт.

P945258

BACK-UP RING

BUSHING

2шт.

P1130447

O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro

SEAL, 3.53 x 31.34-80

2шт.

P1130447

O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro

SEAL, 3.53 x 31.34-80

4шт.

P945258

BACK-UP RING

BUSHING

4шт.

P30318

O-RING

SEAL, 3.6 x 23

2шт.

P30437

O-RING

2.5 x 44

3шт.

P32921

SCREW,Hex Soc Hd, M8 x 20, 10.9

/BOLT, M8 x 20

18шт.

P1340482

CAP

COVER

3шт.

P30324

SEAL

1шт.

P930120

BRACKET

1шт.

P32911

SCREW

/BOLT, M6 x 20

3шт.
