Запчасти Case 50 (148) - PILOT PRESSURE TUBING FROM AUXILIARY PUMP (USED ON UNITS W/ SN. 6280345 & AFTER)(SN. 6279926 & AFTER (35) - HYDRAULIC SYSTEMS

1

218-5172

ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Female JIC

- 45 degrees swivel (3/8" tube) 9/16" - 18 male x 9/16" - 18 male 37 degrees flared

1шт.

2

S7986

FITTING

CONNECTOR - (3/8" tube) 9/16" - 18 male x 1-1/16" - 12 male 37 degrees flared

2шт.

S6065

RING

"O" RING

2шт.

3

A139692

PUMP

- auxiliary, Includes: Ref. 4 - 11

1шт.

4

A45378

SEAL

KIT - pump seal, Includes: Ref. 5 - 11

1шт.

5

A45375

WASHER

RING - back-up

1шт.

6

A59066

O-RING,1.239" ID x 1.379" OD

"O" RING - 1.250" ID x 1.375" OD

1шт.

7

A64434

O-RING,0.93" ID x 1.142" x 0.106"

"O" RING - .937" ID x 1.125" OD

1шт.

8

A45376

COLLAR

- "O" ring

1шт.

9

A45374

RING

- quad

1шт.

10

A45377

SEAL

RETAINER - seal

1шт.

11

A32181

SNAP RING,1.375", Int, #137

Ring, Snap, 1.375", Int, #137

1шт.

12

S232016

HOSE - high pressure 3/8" ID x 100" long (With 9/16" - 18 female pressed on couplings)

1шт.

13

REF

INSTRUCTION

NUT - 3/8" NC (Existing hardware from engine)

2шт.

14

REF

INSTRUCTION

WASHER - lock 3/8" (Existing hardware from engine)

2шт.

15

196-1

WASHER,13/32" x 13/16" x .089", HDN

- flat 3/8"

2шт.

16

S108814

GASKET

1шт.

17

113-252

BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5

CPSW - 3/8" NC x 3-3/8" gr 5

2шт.

18

L43703

GEAR

1шт.

19

195-530

WASHER,7/16"

- flat 1/2"

1шт.

20

131-58

LOCK NUT,1/2"-20, G5

NUT - self locking 1/2" NC

1шт.

21

D32101

SNAP RING,#62, Ext

Ring, Snap, , onto pump shaft #62, Ext

1шт.

22

S7951

ELBOW

- 90 degrees adjustable (5/8" tube) 7/8" - 14 male x 1-1/16" - 12 male 37 degrees flared

2шт.

S6065

RING

"O" RING

2шт.

23

S8581

HOSE ASSY.

HOSE - high pressure 1/2" ID x 48" long (With 7/8" - 14 female pressed on couplings)

1шт.

24

218-445

HYD CONNECTOR,7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

CONNECTOR - (5/8" tube) 7/8" - 14 male x 7/8" - 14 male 37 degrees flared

1шт.

25

218-980

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw

- 90 degrees swivel (3/8" tube) 9/16" - 18 male x 9/16" - 18 female 37 degrees flared

1шт.

26

S227397

HOSE ASSY.

HOSE - high pressure 3/8" ID x 70" long (With 9/16" - 18 female pressed on couplings)

1шт.

27

S8578

HOSE

- high pressure 1/2" ID x 26" long (With 7/8" - 14 female pressed on couplings)

1шт.

28

218-736

UNION,7/8"-14, 37 Degree x 7/8"-14, 37 Degree

- (5/8" tube) - 7/8" - 14 male x 7/8" - 14 male 37 degrees flared

1шт.

29

S8582

HOSE ASSY.

HOSE - high pressure 1/2" ID x 60" long (With 7/8" - 14 female pressed on couplings)

1шт.

30

113-208

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

(Pump to adapter) Hex, 3/8"-16 x 1 1/4", G5, Full Thd

2шт.

31

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

32

S108809

SPROCKET ASSY.

SPROCKET

1шт.

33

S108812

ADAPTER

1шт.

34

S108813

GASKET

1шт.

35

S108810

COUPLING

1шт.

36

S108817

BOLT

CPSW - (Mounts disc to cam shaft gear)

4шт.

37

S86382

GEAR

DISC - (Supersedes S108811)

1шт.

38

113-310

BOLT,Hex, 7/16" - 14 x 1", Gr 5

CPSW - 1/2" NC x 1" gr 5 (Adapter to flywheel housing)

4шт.

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

4шт.

113-424

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

CPSW - 7/16" NC x 1" gr 5 (Adapter to flywheel housing)

1шт.

192-22

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

1шт.

39

218-445

HYD CONNECTOR,7/8" - 14 Male JIC x 1/2" - 14 Male NPTF

ADAPTER - (5/8" tube) 7/8" - 14 male x 1/2" NPT male 37 degrees flared

1шт.

40

S73387

CLIP

TIE - cable

1шт.

41

R14668

CLAMP

1шт.

131-52

NUT,3/8"-16, GC

NUT - self locking 3/8" NC

1шт.
