Запчасти Case 50 (092[1]) - WINDSHIELD WIPER KIT (24 VOLT SYSTEMS) (USED ON SOME UNITS W/ CAB SN. A306825 AND BEFORE) (55) - ELECTRICAL SYSTEMS

S605308

KIT

- wiper 24 volt, Includes: Ref. 1 - 9

1шт.

1

S61798

KIT

- adapter (Includes gaskets)

1шт.

2

S225151

SHAFT

- pivot

1шт.

3

S225152

BLADE

- wiper 22" long

1шт.

4

L35260

ARM

- wiper 20" long

1шт.

5

S61879

MOTOR - modified wiper

1шт.

S61873

PLUG

- (Not illustrated)

1шт.

FOR PUSH TURN LOCKING TYPE CONNECTOR ELECTRICAL PLUG WINDSHIELD WIPER,USE S117619 & S239036 FOR SERIAL NUMBER A306826 AND AFTER.

1шт.

S61874

CLIP

CUP - spring (Not illustrated)

2шт.

S61875

WASHER

- spring (Not illustrated)

1шт.

S61876

LINK

- connecting (Not illustrated)

1шт.

6

S61799

SCREW

- machine (1/4" x 5/8" (Not illustrated)

2шт.

7

A36091

ARM

- drive (Not illustrated)

1шт.

8

S225028

IGNITION SWITCH

SWITCH - wiper (Not illustrated)

1шт.

9

S61880

LIGHT ASSY.

LIGHT - dome (Not illustrated)

1шт.

187-1812

SCREW - machine no. 6 x 3/8" mounts dome light (Not illustrated)

4шт.
