Артикул
Название
Примечание
Количество
1
S506215
HANDLE
hoist - (Includes grease fitting)
1шт.
2
S7397
WASHER
flat - 1/2"
4шт.
3
S17169
INSTRUCTION
NUT, self locking - 1/2" NC
4шт.
4
S215594
BALL
JOINT, ball
3шт.
5
86585245
SPECIAL NUT,JAM, 5/8" - 18
jam - 3/8" NC
4шт.
6
S218942
ROD
connecting
1шт.
7
VALVE, 4-spool main - (For breakdown, see page 127)
1шт.
8
S4640
PIN, cotter - 5/32" x 1" long
1шт.
9
S63411
HANDLE
GRIP, handle - (Used on units without fast hoist)
1шт.
S218254
GRIP
handle - (Used on units with fast hoist)
1шт.
10
S10768
PIN
clevis - 3/8" x 1.016" grip length
1шт.
11
S12514
YOKE
1шт.
12
231-2446
NUT,3/8"-24, GB
NUT, self locking - 3/8" NC
3шт.
13
231-1444
NUT,1/4"-20, GB
NUT, LOCK, 1/4"-20, GB
2шт.
14
S220261
BRACKET
1шт.
15
S217838
SHAFT
1шт.
16
S2352
BOLT
CPSW - 1/4" NC x 1-1/4" gr 5
2шт.
17
S63168
NEEDLE BEARING,0.625" ID x 0.8125" OD x 0.5"
BEARING, needle
6шт.
18
S219366
BRACKET
1шт.
19
S46960
FITTING
grease - 1/4" NPT - (Straight)
1шт.
20
S2523
PIN, roll
1шт.
21
S87535
SHAFT
1шт.
22
S220209
ARM ASSY.
BELLCRANK - (Includes grease fitting)
1шт.
23
S46960
FITTING
grease - 1/4" NPT - (Straight)
1шт.
24
S219036
SUPPORT
1шт.
25
S218962
SHAFT ASSY.
SHAFT
1шт.
26
S87534
ROD
connecting
1шт.
27
S220219
BELLCRANK - (Includes grease fittings)
1шт.
28
S46960
FITTING
grease - 1/4" NPT - (Straight)
1шт.
29
S93485
SPACER
1шт.
Выбрано товаров: 30
