Запчасти Case 50 (058) - SHROUD, GRILLES AND RELATED PARTS, (RIGHT SIDE AND REAR) (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

S505941

DOOR, front

1шт.

2

S2401

BOLT

CPSW - 3/8" NC x 1" gr 5

4шт.

3

S7385

INSTRUCTION

WASHER, flat - 3/8"

4шт.

4

S17167

INSTRUCTION

WASHER, self locking - 3/8"

1шт.

5

S217887

PIN

1шт.

6

S81895

COTTER PIN

PIN, hair

1шт.

7

S219991

SHEET

front

1шт.

8

S2465

BOLT (MACHINE)

CPSW - 1/2" x 1" gr 5

1шт.

9

S86132

WASHER

flat - 1/2"

1шт.

10

S4399

WASHER

lock - 1/2"

1шт.

11

S219992

BRACE - (Right hand)

1шт.

12

S2466

BOLT

CPSW - 1/2" NC x 1-1/4" gr 5

1шт.

13

S17169

INSTRUCTION

NUT, self locking - 1/2" NC

1шт.

14

S220374

BRACKET

1шт.

15

S219989

ANGLE

1шт.

16

S602601

SHROUD, side panel - (Right front)

1шт.

17

S602600

SHROUD, side panel - (Right rear)

1шт.

18

S602603

SHROUD, rear

1шт.

19

S505942

DOOR, rear

1шт.

S2403

BOLT

CPSW - 3/8" NC x 1-1/2" gr 5

2шт.

S7385

INSTRUCTION

WASHER, flat - 3/8"

2шт.

87016560

JAM NUT,Jam, 3/8"-16, G5

- 3/8" NC

2шт.

20

S219460

BRACE

- (Right hand)

1шт.

21

S219473

BRACE

- (Left hand)

1шт.

S2350

MUFFLER

CPSW - 1/4" NC x 3/4" gr 5

6шт.

231-1444

NUT,1/4"-20, GB

NUT, LOCK, 1/4"-20, GB

10шт.

S7380

WASHER

flat - 1/4"

4шт.

S2351

BOLT

CPSW - 1/4" NC x 1" gr 5

4шт.

22

S219993

BRACE - (Left hand)

1шт.

23

S219346

LATCH

door

1шт.

24

S221453

BRACKET

hinge

1шт.

25

S221455

BRACKET

hinge

1шт.

26

S94090

SPACER

shroud mounting

3шт.
