Запчасти Case 50 (G13) - DRAIN LINE CIRCUIT TUBING, (SWING AND TRACK DRIVE MOTORS) (35) - HYDRAULIC SYSTEMS

1

209678

LINE, hydraulic

1шт.

2

77121

HOSE, high pressure - 1/4" ID x 20 long - (With 9/16" - 18 female pressed on couplings)

1шт.

3

5006

ELBOW, 45 degree flared - (3/8" tube) - 9/16" - 18 male x 1/4" NPT male

1шт.

4

MOTOR, swing - (For breakdown, see section "H")

1шт.

5

45219

CLAMP

1шт.

2400

LAMP

CPSW - 3/8" x 3/4" NC grade 5

1шт.

7387

LOCTITE

WASHER, flat - 13/32"

1шт.

4397

LOCKWASHER, 3/8"

1шт.

6

208880

LINE, hydraulic

1шт.

7

45219

CLAMP

1шт.

2402

LAMP

CPSW - 3/8" x 1-1/4" NC grade 5

1шт.

7387

LOCTITE

WASHER, flat - 13/32"

1шт.

4397

LOCKWASHER - 3/8"

1шт.

4222

NUT - 3/8" NC

1шт.

8

10873

CLAMP, hose - (Fits hoses 3/4" O.D. x 1" O.D.)

2шт.

9

202581

HOSE, low pressure - (Bulk) - 1 piece - 1" ID x 8" long

1шт.

10

RESERVOIR, hydraulic oil - (For breakdown, see section "H")

1шт.

11

60838

ADAPTER, flared - (1" tube) - 1-5/16" - 12 male x 3/4" NPT male

1шт.

12

208879

LINE, hydraulic

1шт.

13

9419

TANK

CAP - (1" tube) - 1-5/16" - 12 female

1шт.

14

45219

CLAMP

1шт.

2403

LAMP

CPSW - 3/8" x 1-1/2" NC grade 5

1шт.

7389

WASHER, flat - 7/16"

1шт.

17167

LOCK NUT

NUT, self locking - 3/8" NC

1шт.

15

78402

BRACKET

1шт.

2351

LAMP

CPSW - 1/4" x 1" NC grade 5

2шт.

4395

WASHER

LOCKWASHER - 1/4" NC

2шт.

4220

TOOL

NUT - 1/4" NC

2шт.

16

MOTOR, track drive - (For breakdown, see section "H")

2шт.

17

101310

ADAPTER

flared - (1/2" tube) - 3/4" - 16 male x 1/4" NPT male - 37 degree flared

2шт.

18

10357

BRACKET

ELBOW, 90 degree swivel - (1/2" tube) - 3/4" - 16 male x 3/4" - 16 female - 37 degree flared

3шт.

19

206892

LINE, hydraulic

2шт.

20

11230

HOSE, high pressure - 3/8" ID x 28" long - (With 3/4" - 16 female pressed on couplings)

3шт.

21

211644

LINE, hydraulic - to right hand track drive motor

1шт.

22

60498

SPARE PART

TEE, flared - (1/2" tube) - 3/4" - 16 male x 3/4" - 16 male x 3/4" x 16 male - 37 degree flared

1шт.

23

211643

LINE, hydraulic - to left hand track drive motor

1шт.

24

79585

CLAMP

2шт.

2402

LAMP

CPSW - 3/8" x 1-1/4" NC grade 5

2шт.

7387

LOCTITE

WASHER, flat - 13/32"

2шт.

4397

LOCKWASHER - 3/8"

2шт.

4222

NUT - 3/8" NC

2шт.

25

15543

CLAMP

- use existing mounting hardware

2шт.

26

211650

LINE, hydraulic

1шт.

27

101833

ADAPTER, reducing - (3/4" to 1/2" reduction) - 3/4" - 16 male - 37 degree flared

1шт.

6227

NUT, tube - (3/4" tube) - 1-1/16" - 12 female - 37 degree flared

1шт.

29

SWIVEL, hydraulic - (For breakdown, see section "H")

1шт.
