Запчасти Case 40BLC (084) - AUXILIARY CONTROL LINKAGE, (USED WITH 16" FELLER BUNCHER) (05) - UPPERSTRUCTURE CHASSIS

1

131-70

NUT,1/2"-13, GB

NUT, self locking - 1/2" NC

4шт.

2

95-8

WASHER,1/2"

flat 1/2"

4шт.

3

S218944

BRACKET

1шт.

4

S63168

NEEDLE BEARING,0.625" ID x 0.8125" OD x 0.5"

BEARING, needle

4шт.

5

S215594

BALL

JOINT, ball

5шт.

6

86585245

SPECIAL NUT,JAM, 5/8" - 18

jam -3/8" NC

6шт.

7

S219275

ROD

connecting

1шт.

8

VALVE, 4-spool main control - (For breakdown, see page 260)

1шт.

9

132-67

COTTER PIN,5/32" x 3/4"

PIN, cotter - 5/32" x 1" long

1шт.

10

S10768

PIN

cleviks - 3/8" x 1.016" grip length

1шт.

11

231-2446

NUT,3/8"-24, GB

NUT, self locking - 3/8" NF

4шт.

12

S220208

BELLCRANK - (Includes item 13)

1шт.

13

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

1шт.

14

S218943

BRACKET

1шт.

15

113-17

BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5

2шт.

16

S218963

SHAFT

1шт.

17

86625061

NUT,1/4"-20, GB

NUT, self locking - 1/4" NC

2шт.

18

S87534

ROD

connecting

1шт.

19

132-95

COTTER PIN,3/16" x 1 1/2"

Pin, Split (Cotter), 3/16" x 1 1/2"

1шт.

20

S88670

SPACER

1шт.

21

S91682

ROD, connecting

1шт.

22

S216744

BELLCRANK - (Includes item 23)

1шт.

23

S46960

FITTING

grease - 1/4" NPT - (Straight)

1шт.

24

S219056

SHAFT

1шт.

25

S40815

BEARING, NEEDLE,0.375" ID x 0.5630" OD x 0.312"

1шт.

26

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

YOKE

1шт.

27

131-493

NUT

self locking - 3/8" NF

1шт.

195-525

WASHER,3/8", SAE

flat - 3/8"

2шт.
