Запчасти Case 40 (008) - INTAKE MANIFOLD, 504BDT ENGINE (10) - ENGINE

1

A66087

MANIFOLD

ASSY. - intake

1шт.

2

A20916

MANIFOLD GASKET

GASKET - plug

2шт.

3

L10283

PLUG

- heater opening

2шт.

4

221-1849

PLUG

- pipe, 1/8" PT hex socket head

2шт.

5

41-1042

PLUG,Cup, 2 5/8"

- cup, 2-5/8" dia

1шт.

6

A58662

MANIFOLD GASKET

-, Serial Range: manifold-head

6шт.

7

A59077

STUD

- manifold to head, 3/8" NC x 1-3/4" (44.45 MM)

12шт.

8

195-25

WASHER,3/8"

- 3/8 x 13/16 x 1/16"

12шт.

9

92-6

LOCK WASHER,3/8"

12шт.

10

25-166

NUT,3/8"-16, G5, Hvy

- 3/8" NC hex

12шт.

14

A76322

MANIFOLD

- center section, exhaust

1шт.

15

A65917

MANIFOLD

- end section, exhaust

2шт.

16

A58895

GASKET

- manifolds to head, exhaust

6шт.

17

A140924

STUD

- manifolds to head, 3/8" NC x 2-7/16" (61.91 MM), exhaust

12шт.

18

92-6

LOCK WASHER,3/8"

exhaust manifold 3/8"

12шт.

19

131-903

NUT,3/8"-16

NUT - 3/8" NC hex Seez-Pruf, exhaust manifold

12шт.

23

A76351

GUARD

SHIELD - heat, exhaust manifold

1шт.

24

195-25

WASHER,3/8"

- 3/8 x 13/16 x 1/16", exhaust manifold

6шт.
