Запчасти Case 30YM (060) - CRAWLER STRUCTURALS, GROUP II CRAWLER UNDERCARRIAGE - 5 ROLLER FOR 32 PAD TRACK (05) - UPPERSTRUCTURE CHASSIS

Items 1-26 are the same as Group I, see Figure 058

1шт.

27

3014103R2

JAW

SHOE, track (14" wide) (32 per track)

32шт.

202540

SHOE, track (16" wide) (32 per track)

32шт.

201102

SHOE, track (19" wide) (32 per track)

32шт.

53006

SPIDER

SHOE, track (20" wide) (32 per track)

32шт.

*30

78500

DRIVE CHAIN, (Bulk) One complete chain consists of 66 offset pitches. (Standard for units with serial number 464-up) (See note) (2 per crawler)

2шт.

*31

103152

LINK, master (For repair of straight roller chain only. Used on units with serial number 1 thru 463.

1шт.

34

54706

SHIELD, track fits 16" or 20" shoe for left front or right rear - outside (2 per crawler) OPTIONAL EQUIPMENT ( FOR 32 PAD )

2шт.

35

54707

SHIELD, track fits 16" or 20" shoe for left rear or right front - outside (2 per crawler) OPTIONAL EQUIPMENT ( FOR 28 PAD )

2шт.

36

205060

PLATE, splice for 16" or 20" track shields (2 per crawler) OPTIONAL EQUIPMENT ( FOR 32 PAD )

2шт.
