Запчасти Case 30YC (C10) - GMC 3-53 DIESEL ENGINE, (DROTT #55949 AND MOUNTING PARTS) (01) - ENGINE
№
Артикул
Название
Примечание
Количество
1
209070
MUFFLER
1шт.
1a
78776
ADAPTER
1шт.
2
65065
CLAMP - muffler
1шт.
3
76701
HOSE - radiator, upper
1шт.
10878
CLAMP - hose
2шт.
4
62939
V-BELT
2шт.
5
56172
RADIATOR, Includes Ref. 6
1шт.
6
73374
CAP - radiator
1шт.
7
36359M1
COOLER- oil
1шт.
8
49610
DRAIN - radiator
1шт.
9
71931
HOSE, bulk, 2" ID x 18" long
1шт.
Change in listing.
1шт.
10878
CLAMP - hose
2шт.
10
76819
CPSW - 5/16" x 1-3/8" NC grade 5
12шт.
7344
WASHER - flat - 5/16"
12шт.
4397
LOCKWASHER - 5/16"
12шт.
11
36393
BRACKET - front engine mounting
1шт.
2412
LAMP
CPSW - 3/8" x 3-3/4" NF grade 5
2шт.
4397
LOCKWASHER - 3/8"
2шт.
2431
FITTING
CPSW - 7/16" x 1-1/4" NC grade 5
2шт.
4398
LOCKWASHER - 7/16"
2шт.
12
2511
FLEXIBLE HOSE
CPSW - 5/8" x 3-3/4" NC
1шт.
64712
SNAP RING,#43, Ext
MOUNTING - compression
1шт.
49559
WASHER - snubbing
1шт.
17174
LOCKNUT - 5/8" NC
1шт.
13
33200
CLAMP
DAMPENER, Consists of Refs. 14 and 15
1шт.
14
201639
DAMPER
1шт.
63218
CPSW - 3/8" x 5/8" NC grade 5
8шт.
15
33114
SPACER
PILOT
1шт.
16
63071
SPACER
1шт.
17
38947
SPARE PART
BRACKET - rear engine mounting - right side
1шт.
2471
DISC
CPSW - 1/2" x 2-1/4" NC grade 5
4шт.
4399
WASHER
LOCKWASHER - 1/2"
4шт.
2468
TACHOMETER
CPSW - 1/2" x 1-3/4" NC grade 5
8шт.
4399
WASHER
LOCKWASHER - 1/2"
8шт.
4224
NUT - 1/2" NC
8шт.
51610
BRACKET - rear engine mounting - left side, not illustrated
1шт.
2466
ENGINE
CPSW - 1/2" x 1/4" NC grade 5
4шт.
4399
WASHER
LOCKWASHER - 1/2"
4шт.
18
63201
COUPLING - pump drive
1шт.
19
52615
REAR FENDER
BRACKET - pump mounting
1шт.
2401
LAMP
CPSW - 3/8" x 1" NC grade 5
12шт.
4397
LOCKWASHER - 3/8"
12шт.
20
207867
PIPE - exhaust
1шт.
21
57722
SHROUD - radiator
1шт.
14458
ELEC. TERMINAL PIN,8 - 10
SCREW - machine, shroud to radiator, 1/4" x 5/16" NC
6шт.
7342
LOCKWASHER - internal tooth - 1/4"
6шт.
Выбрано товаров: 47
