(35.106.AD[05]) - VAR - 461863 - VARIABLE DELIVERY HYDRAULIC PUMP, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL

Запчасти Case CX500D LC (35.106.AD[05]) - VAR - 461863 - VARIABLE DELIVERY HYDRAULIC PUMP, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX500D LC - (35.106.AD[05]) - VAR - 461863 - VARIABLE DELIVERY HYDRAULIC PUMP, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
35.104.aa 01
1
5
3
2
6
4
35.106.ad 06
35.106.ab 02
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KTJ15671

HYDRAULIC PUMP

ASSY

1шт.

2

KTJ2232

COUPLING

ASSY, Incl 3 - 5

1шт.

3

KTJ2234

FLANGE

1шт.

4

KTJ2100

BOLT,Spcl

M16 x 55mm

1шт.

5

KTJ2233

HUB

1шт.

6

862-10035

HEX SOC SCREW,M10 x 35mm, Cl 12.9

8шт.
