(35.106.AO[02]) - VARIABLE DELIVERY HYDRAULIC PUMP, PRESSURE PIPE, BRACKET

Запчасти Case CX500D LC (35.106.AO[02]) - VARIABLE DELIVERY HYDRAULIC PUMP, PRESSURE PIPE, BRACKET (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX500D LC - (35.106.AO[02]) - VARIABLE DELIVERY HYDRAULIC PUMP, PRESSURE PIPE, BRACKET (35) - HYDRAULIC SYSTEMS
39.101.ac 02
4
3
6
7
2
2
7
3
1
8
5
4
39.101.ac 01
35.359.ab 01
35.106.ao 01
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KTJ15810

BRACKET

1шт.

2

KTJ15980

CLAMP

2шт.

3

105R012Y025R

BOLT

M12 x 25mm

4шт.

4

166052A1

BOLT

M10 x 25mm

3шт.

5

KBJ23200

PLATE

1шт.

6

KTJ15820

BRACKET

1шт.

7

KRJ11450

HOSE CLIP

2шт.

8

KRJ10800

PLATE

1шт.
