Запчасти Case CX350D LC (88.100.35[223]) - DIA KIT, QUICK COUPLER, SOLENOID VALVE, HYDRAULIC LINE (88) - ACCESSORIES

1

KG1SP209-00

CONSTRUCTION DIA

Quick Coupler Line, Incl 2 - 15

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

2

NSS

NOT SOLD SEPARAT

45° Fitting, Incl in 15

1шт.

3

154467A1

O-RING,10.8mm ID x 2.4mm Width

1шт.

4

KSJ22640

HYDRAULIC HOSE

9mm ID x 630mm

1шт.

5

KSJ22600

PIPE

1шт.

6

169149A1

COLLAR

1шт.

7

150811A1

WASHER

3шт.

8

627-12045

BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd

1шт.

9

627-12020

BOLT,Hex, M12 x 1.75 x 20mm, Cl 10.9, Full Thd

2шт.

10

KSJ22620

PLATE

1шт.

11

150496A1

MOUNTING CLIP

7шт.

12

KHJ15300

TEE

1шт.

13

KHJ32030

HYDRAULIC HOSE

1шт.

14

KHV13450

HYDRAULIC HOSE

2шт.

15

161087A1

ELBOW

ASSY, Incl 2, 3

1шт.
