(88.100.35[212]) - DIA KIT, SAFETY VALVE, ARM, LIFT CYLINDER, CHECK VALVE, LINE

Запчасти Case CX350D LC (88.100.35[212]) - DIA KIT, SAFETY VALVE, ARM, LIFT CYLINDER, CHECK VALVE, LINE (88) - ACCESSORIES

Схема запчастей Case CX350D LC - (88.100.35[212]) - DIA KIT, SAFETY VALVE, ARM, LIFT CYLINDER, CHECK VALVE, LINE (88) - ACCESSORIES
1
88.100.35 (211)
4
35.359.ab (01)
35.300.aq
88.100.35 (211)
5
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KG1SP092-00

CONSTRUCTION DIA

Hose Burst Check Valve, Incl 2 - 5

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

2

KHJ31880

TEE

1шт.

3

KHJ17030

HYDRAULIC HOSE

1шт.

4

KHJ16330

HYDRAULIC HOSE

1шт.

5

KHJ11560

TEE

1шт.
