(35.360.AK[01]) - VAR - 461869 - BOOM, LINE, HAMMER, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL

Запчасти Case CX350D LC (35.360.AK[01]) - VAR - 461869 - BOOM, LINE, HAMMER, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX350D LC - (35.360.AK[01]) - VAR - 461869 - BOOM, LINE, HAMMER, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
7
10
5
10
9
8
4
1
35.360.ae (02)
4
6
2
5
7
1
35.360.ab (04)
8
2
35.360.ab (03)
35.360.ak (02)
35.360.ak (02)
9
6
3
2
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KHJ25900

SOCKET

ASSY, Incl 2 (Qty 1), 4

2шт.

2

154523A1

O-RING

4шт.

3

KHJ1349

ADAPTER

ASSY, Incl 2 (Qty 1), 9

2шт.

4

NSS

NOT SOLD SEPARAT

Fitting, Incl in 1

2шт.

5

KSJ19110

HOSE

25mm ID x 1670mm

2шт.

6

150124A1

FLANGE

4шт.

7

164450A1

O-RING

2шт.

8

108R014Y055R

BOLT

8шт.

9

NSS

NOT SOLD SEPARAT

Fitting, Incl in 3

2шт.

10

KHJ1361

O-RING,0.07" Thk x 0.926" ID

2шт.

Выбрано товаров: 10
