Запчасти Case CX300D LC (35.360.AB[03]) - VAR - 461869 - HAMMER CIRCUIT, LINE, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

1

KHJ1804

ELBOW

ASSY, Incl 2, 3

1шт.

2

154503A1

O-RING

3шт.

3

NSS

NOT SOLD SEPARAT

90°-Fitting, Incl in 1

1шт.

4

KHJ26310

STUD

1шт.

5

KHJ1360

O-RING,0.07" Thk x 0.739" ID

2шт.

6

KBJ12520

HYDRAULIC HOSE,19.00 mm ID x 1250.00 mm

1шт.

7

KBJ23800

HYDRAULIC HOSE

25 x 1000mm

1шт.

8

862-10030

HEX SOC SCREW,M10 x 30mm, Cl 12.9

4шт.

9

153459A1

FLANGE

2шт.

10

155211A1

O-RING

1шт.

11

KHJ1361

O-RING,0.07" Thk x 0.926" ID

1шт.

12

KHJ11370

ELBOW

ASSY, Incl 13, 14

1шт.

13

154523A1

O-RING

1шт.

14

NSS

NOT SOLD SEPARAT

45°-Fitting, Incl in 12

1шт.

15

KBJ13790

HYDRAULIC HOSE,740.00 mm

1шт.

16

157586A1

ELBOW

ASSY, Incl 2, 18

2шт.

17

KHJ1215

BOLT,Spcl

M8 x 25mm

1шт.

18

NSS

NOT SOLD SEPARAT

45°-Fitting, Incl in 16

2шт.

19

KHJ25900

SOCKET

ASSY, Incl 20, 21

1шт.

20

152211A1

O-RING

1шт.

21

NSS

NOT SOLD SEPARAT

Socket, Incl in 19

1шт.

22

KBJ16300

BRACKET, SUPPORTING

1шт.

23

166352A1

BOLT

M12 x 30mm

8шт.

24

KRJ11470

SUPPORT

1шт.

25

KHR2584

CLAMP

1шт.
