Запчасти Case CX290D LC SL (35.946.020) - ELEVATOR, FRAME, HYDRAULIC CYLINDER (35) - HYDRAULIC SYSTEMS

1

KRJ14551

HYDRAULIC CYLINDER

1шт.

2

KRB16790

PIN

1шт.

3

KRB12150

PIN

1шт.

4

KRJ7062

BOLT,Drilled

M12 x 1.25 x 120mm

2шт.

5

172R012VR

NUT

M12 x 1.25

2шт.

6

175R012HSR

SLOTTED NUT

M12 x 1.25

2шт.

7

330-032S028R

COTTER PIN

3.2mm x 28mm

2шт.

8

KRJ6797

WASHER

T=0.5 Thk

10шт.

9

KSJ20090

BRACKET

1шт.

10

627-16045

BOLT,Hex, M16 x 2 x 45mm, Cl 10.9, Full Thd

6шт.

11

KHA0012

WASHER

6шт.

12

KRJ7063

STOP DEVICE

1шт.

13

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

2шт.

14

150409A1

WASHER

M12

2шт.

15

KHJ19810

ORIFICE

1шт.

16

152127A1

HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT

ASSY, G1/4" x G1/4", Incl 17 (Qty 1)

1шт.

17

150960A1

O-RING,10.8mm ID x 2.4mm Width

2шт.

18

159848A1

ORIFICE

ASSY, Incl 17 (Qty 1)

1шт.

19

163814A1

ELBOW

3шт.

20

168691A1

HYDRAULIC HOSE,6.30 mm ID x 420.00 mm

From Cylinder to Main Control Valve

1шт.

21

KNJ0500

HYDRAULIC HOSE

From Cylinder to Main Control Valve

1шт.

22

AFV0041

HYDRAULIC HOSE

From Cylinder to Valve Stop

1шт.
