Запчасти Case CX250D LC LR (88.100.55[20]) - DIA KIT, RIGHT, SIDE CAMERA, WIRE HARNESS (88) - ACCESSORIES

1

KG0RR844-00

CONSTRUCTION DIA

Right Side Camera, Incl 2 - 8

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

2

KHN2132

BOLT,Hex Flg Hd, M6 x 16

1шт.

3

157806A1

COLLAR

1шт.

4

KHR28651

WIRE HARNESS

Side Camera, 9000mm

1шт.

5

KHR10220

MOUNTING CLIP

3шт.

6

150496A1

MOUNTING CLIP

250mm

20шт.

7

150498A1

MOUNTING CLIP

297mm

6шт.

8

KMR0307

GROMMET

1шт.
