(35.300.AQ[03]) - VAR - 461869 - HYDRAULIC OIL RESERVOIR, HAMMER CIRCUIT, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL

Запчасти Case CX250D LC (35.300.AQ[03]) - VAR - 461869 - HYDRAULIC OIL RESERVOIR, HAMMER CIRCUIT, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX250D LC - (35.300.AQ[03]) - VAR - 461869 - HYDRAULIC OIL RESERVOIR, HAMMER CIRCUIT, SHEARS, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
90.150.aw
5
8
6
7
10
6
9
9
7
2
6
12
12
7
3
2
6
8
11
2
7
8
1
5
8
4
35.300.aq (01)
35.106.ad (01)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

152127A1

HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT

ASSY, Incl 2 (Qty 1), 10

1шт.

2

154467A1

O-RING,10.8mm ID x 2.4mm Width

1шт.

3

169040A1

ADAPTER

ASSY, Incl 4, 11

1шт.

4

154523A1

O-RING

1шт.

5

KHJ28580

ELBOW

ASSY, Incl 2 (Qty 1), 12

2шт.

6

150860A1

COLLAR

4шт.

7

840-168

SCREW,Pan, M6 x 1 x 8mm, Cl 4.8

4шт.

8

150496A1

MOUNTING CLIP

4шт.

9

KHJ15060

CAP

2шт.

10

NSS

NOT SOLD SEPARAT

Fitting, Incl in 1

1шт.

11

NSS

NOT SOLD SEPARAT

Fitting, Incl in 3

1шт.

12

NSS

NOT SOLD SEPARAT

90° Fitting, Incl in 5

2шт.
