/ / / / / / / / (10.500.AD[03]) - DEF/ADBLUE™ TANK, SUPPLY LINES
Запчасти Case CX210D NLC (10.500.AD[03]) - DEF/ADBLUE™ TANK, SUPPLY LINES (10) - ENGINE
![Схема запчастей Case CX210D NLC - (10.500.AD[03]) - DEF/ADBLUE™ TANK, SUPPLY LINES (10) - ENGINE](https://partsell.ru/storage/images/casece/5402457.png)
10.500.ad (02)
2
4
5
4
6
11
10
14
3
1
9
6
4
10
4
2
12
13
4
6
15
9
7
16
16
8
3
55.988.am
10.500.ao (01)
10.001.ad
1
KHH18010
HOSE
11mm ID x 2100mm
1шт.
2
KHR21050
PLASTIC-RUBBER TUBE
19mm ID x 2000mm
2шт.
3
KHH16800
BAND
6шт.
4
KHH15490
ELBOW
1шт.
5
152137A1
TEE
G3/8"
1шт.
6
KRR21150
NIPPLE
3шт.
7
KHH15980
HOSE
11mm ID x 2000mm
1шт.
8
KHR2581
CLAMP
5шт.
9
162149A1
COLLAR
2шт.
10
167518A1
BOLT
M8 x 16mm
2шт.
11
KHH15970
HOSE
11mm ID x 1700mm
1шт.
12
KHR13930
PROTECTIVE SLEEVE
19mm ID x 1600mm
1шт.
13
KHR10220
MOUNTING CLIP
1шт.
14
150496A1
MOUNTING CLIP
1шт.
15
KHR2584
CLAMP
M8
11шт.
16
KHJ1215
BOLT,Spcl
M8 x 25mm
12шт.
