(90.105.BV[09]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION

Запчасти Case CX210D NLC (90.105.BV[09]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case CX210D NLC - (90.105.BV[09]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION (90) - PLATFORM, CAB, BODYWORK AND DECALS
39.101.ac
6
4
5
3
2
1
90.105.bv (07)
90.105.bv (07)
90.105.bv (07)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KRN29340

SEAL

, Serial Range: -C0490

1шт.

1

KRN29341

SEAL

, Start Serial: D0490

1шт.

2

KRN29331

SEAL

1шт.

3

KRN29301

SEAL

1шт.

4

KRN29320

SEAL

1шт.

5

KBN16790

SEAL

1шт.

6

KRN14150

SEAL

1шт.
