(90.105.BV[06]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION

Запчасти Case CX210D NLC (90.105.BV[06]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case CX210D NLC - (90.105.BV[06]) - STD + VAR - 488031 - HOUSING & COVERS, INSULATION (90) - PLATFORM, CAB, BODYWORK AND DECALS
90.105.bv (05)
9
1
9
4
7
8
7
8
7
10
9
1
2
3
6
8
5
11
35.300.aq
90.105.bv (05)
90.105.bv (05)
90.105.bv (05)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KBN16520

INSULATION

2шт.

2

KBN20060

SEAL

1шт.

3

KBN16410

SEAL

1шт.

4

KBN19810

SEAL

1шт.

5

KRN29290

INSULATION

1шт.

6

KRN29360

SEAL

, Serial Range: -C0479

1шт.

6

KRN29361

SEAL

, Start Serial: D0479

1шт.

7

827-8040

BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9

7шт.

8

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

7шт.

9

KHH0358

RETAINER

7шт.

10

KBN19830

SEAL

1шт.

11

KBN19930

SEAL

1шт.
