(35.738.AE[04]) - VAR - 481268 - BUCKET CYLINDER, LINES (ARM L=2.94M)

Запчасти Case CX210D LC (35.738.AE[04]) - VAR - 481268 - BUCKET CYLINDER, LINES (ARM L=2.94M) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX210D LC - (35.738.AE[04]) - VAR - 481268 - BUCKET CYLINDER, LINES (ARM L=2.94M) (35) - HYDRAULIC SYSTEMS
35.738.ae (02)
35.738.aa (01)
3
35.738.ae (02)
1
2
84.100.am (02)
84.912.aa (02)
5
6
5
2
84.100.aq (04)
7
4
8
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KHJ1348

ADAPTER

ASSY, Incl 7 - 8

1шт.

2

KHJ1361

O-RING,0.07" Thk x 0.926" ID

2шт.

3

KRV22580

HYDRAULIC HOSE,22.2mm ID x 1550mm L

1550mm

1шт.

4

KHJ15840

ADAPTER

G3/4"

1шт.

5

KHJ1360

O-RING,0.07" Thk x 0.739" ID

2шт.

6

KRV12791

HYDRAULIC HOSE

19mm ID x 1550mm

1шт.

7

154503A1

O-RING

1шт.

8

NSS

NOT SOLD SEPARAT

Fitting, Incl in 1

1шт.

Выбрано товаров: 8
