Запчасти Case CX210D LC (35.360.AB[05]) - VAR - 461869, 461870 - DIRECTIONAL CONTROL VALVE, HAMMER CIRCUIT, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
![Схема запчастей Case CX210D LC - (35.360.AB[05]) - VAR - 461869, 461870 - DIRECTIONAL CONTROL VALVE, HAMMER CIRCUIT, HIGH FLOW, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS](https://partsell.ru/storage/images/casece/5404008.png)
35.360.ab (06)
1
2
3
3
39.101.ac
№
Артикул
Название
Примечание
Количество
1
KHJ10420
VALVE SECTION
ASSY
1шт.
2
KRJ16050
SUPPORT
1шт.
3
166352A1
BOLT
M12 x 30mm
6шт.
Выбрано товаров: 3
