(88.100.35[073]) - DIA KIT, AUXILIARY CIRCUIT, SHEARS, W/ ELECTRICAL PROPORTIONAL CONTROL, BOOM, LINE

Запчасти Case CX160D LC (88.100.35[073]) - DIA KIT, AUXILIARY CIRCUIT, SHEARS, W/ ELECTRICAL PROPORTIONAL CONTROL, BOOM, LINE (88) - ACCESSORIES

Схема запчастей Case CX160D LC - (88.100.35[073]) - DIA KIT, AUXILIARY CIRCUIT, SHEARS, W/ ELECTRICAL PROPORTIONAL CONTROL, BOOM, LINE (88) - ACCESSORIES
11
5
6
35.360.ak (07)
35.360.ak (06)
9
10
35.360.ak (08)
35.360.ak (08)
3
88.100.35 (072)
8
6
84.910.aa
2
88.100.35 (072)
2
35.360.ak (06)
7
4
35.360.ak (07)
9
10
6
1
6
11
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KG0LP424-00

CONSTRUCTION DIA

Double Acting Circuit, Incl 2 - 11

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.

2

NSS

NOT SOLD SEPARAT

Plug, Incl in 9

2шт.

3

150542A1

O-RING

2шт.

4

KLV13700

HYD TUBE,Dia 27.2

1-3/16'' ID, RH

1шт.

5

KLV13710

HYD TUBE,Dia 27.2

1-3/16'' ID, LH

1шт.

6

KHJ1360

O-RING,0.07" Thk x 0.739" ID

4шт.

7

KLV12390

HYD TUBE,27.2mm X 20.8mm Adaptor

RH

1шт.

8

KLV12380

HYD TUBE,20.8 mm ID x 27.2 mm OD Adaptor

LH

1шт.

9

152924A1

PLUG

ASSY, G3/4", Incl 2, 3

2шт.

10

KHV10460

COLLAR CLAMP

4шт.

11

KHV10450

COLLAR CLAMP

8шт.
