(35.359.AB[08]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL

Запчасти Case CX130D (35.359.AB[08]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX130D - (35.359.AB[08]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
2
35.359.ab (09)
4
4
3
1
39.101.ac
3
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KNJ21960

CONTROL VALVE

ASSY

1шт.

See also Figure 35.359.AB(09), 35.359.AB(10), 35.359.AB(11), 35.359.AB(12), 35.359.AB(13), 35.359.AB(14), 35.359.AY(06), 35.359.AY(07)

1шт.

2

KNJ16710

BRACKET

1шт.

3

166373A1

BOLT,Sems, M16 x 40mm

8шт.

4

102R012Y016R

BOLT

M12 x 16mm

2шт.
