Запчасти Case CX75C SR (35.736.AC[16]) - VAR - 461865, 461868 - BOOM CYLINDER LINE (35) - HYDRAULIC SYSTEMS

1

166400A1

COLLAR

10шт.

2

150811A1

WASHER

2шт.

3

827-12065

BOLT,Hex, M12 x 1.75 x 65mm, Cl 10.9

1шт.

4

827-12070

BOLT,Hex, M12 x 1.75 x 70mm, Cl 10.9

1шт.

5

KAV20640

BRACKET

1шт.

6

166352A1

BOLT

2шт.

7

167183A1

BOLT,Sems, M12 x 60mm, Cl 10.9

8шт.

8

KHV12270

SCREW,M12 x 1

3шт.
