Запчасти Case CX470C (02-038-01[01]) - AIR COMPRESSOR (01) - ENGINE

0-10

84477174

COVER

1шт.

See Figure(s) 02-010-01-01

1шт.

0-11

84160077

CYLINDER HEAD

1шт.

See Figure(s) 02-011-01-01

1шт.

0-11

47607709R

REMAN-CYLINDER HEAD

Complete Reman Cylinder Head With Valves

1шт.

0-11

47607709C

CORE-CYLINDER HEAD

Return Number

1шт.

0-11

47828375R

REMAN-CYLINDER HEAD

Complete Reman Cylinder Head With Valves

1шт.

0-11

47828375C

CORE-CYLINDER HEAD

Core Return Number

1шт.

0-12

84477120

BLOCK,6 Cylinders, W/O Turbocharger

1шт.

See Figure(s) 02-012-01 01

1шт.

0-25

84477009

BRACKET

1шт.

See Figure(s) 02-025-02 01

1шт.

0-27

87603424

EXHAUST MANIFOLD

1шт.

See Figure(s) 02-027-01-01

1шт.

0-31

87603793

HOSE CLIP

1шт.

See Figure(s) 02-031-02 01

1шт.

0-32

84477615

PIPE

1шт.

See Figure(s) 02-032-01-01

1шт.

0-57

87646088

COOLER

1шт.

See Figure(s) 02-057-02 01

1шт.

116a

84476955

BRACKET

1шт.

116b

84477066

BRACKET

1шт.

193a

87595292

BOLT

2шт.

193b

87605814

BOLT

3шт.
