Запчасти Case CX350C (04-016[00]) - ELECTRICAL ACCESSORIES - ENGINE (04) - ELECTRICAL SYSTEMS

0-61

87603745

BOLT

1шт.

See Figure(s) 04-061-01 01

1шт.

1

84389463

STARTER MOTOR,24V, 5kW

24V 5.0Kw

1шт.

1

84389463R

REMAN-STARTER,24V, 5kW

CX350C CRAWLER EXCAVATOR TIER 4 (NA), 24V 5.0Kw

1шт.

1

84389463C

CORE-STARTER,24V, 5kW

Return Number

1шт.

2

438007A1

ALTERNATOR

1шт.

2

438007A1R

REMAN-ALTERNATOR

CX350C, Tier 4

1шт.

2

438007A1C

CORE-ALTERNATOR

Return Number

1шт.

7

84387702

NUT

2шт.

10

84364501

RELAY

(Used for Starter)

1шт.

16

289045A1

BOLT

1шт.

17

87597767

WASHER

1шт.

18

84387706

WASHER

1шт.

19

72109824

BRACKET

1шт.

23

437982A1

SUPPORT

1шт.

26

87597774

BOLT,Flng, M10 x 80mm

3шт.

46

87384054

RELAY

(Used for Glow Plug)

1шт.

292

84387706

WASHER

2шт.

293

438016A1

CABLE ASSY.

1шт.

613

84389358

ECU

1шт.

613

84490806R

REMAN ELECT CONTROL

CX350C CRAWLER EXCAVATOR TIER 4 (NA), Reman for New PN 84389358

1шт.

613

84490806C

CORE-ELECTRONIC CONT

Return Number

1шт.

796

87379337

SENSOR

Pressure

1шт.

819

84364495

TEMPERATURE SENDER

(Used for Inlet Air)

1шт.
