Запчасти Case CX250C (09-008[00]) - COWLING - FRONT RIGHT HAND-SIDE CABINET (09) - CHASSIS/ATTACHMENTS

123

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

2шт.

124

153077A1

COTTER PIN

2шт.

125

KRN16030

SEALING STRIP

1шт.

126

KHN24400

GAS STRUT

4шт.

127

KHN12730

LOCK

1шт.

128

166351A1

BOLT,Sems, M10 x 20mm

M10 x 20

2шт.

129

KHN12740

SUPPORT

1шт.

130

166350A1

BOLT

4шт.

131

KRN12360G1

COVER

1шт.

Include(s) 132

1шт.

132

KHN3390

HINGE

2шт.

133

KRN12350G1

COVER

1шт.

134

166350A1

BOLT

M8 x 20

2шт.

135

152718A1

BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9

5шт.

136

KRN12370G1

COVER

1шт.

137

152718A1

BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9

2шт.

138

KRN12790

SEAL PROTECTION

1шт.

139

KHN12710Y2

COVER

1шт.

140

KHN12720

SUPPORT

1шт.

141

152718A1

BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9

5шт.

142

166352A1

BOLT

1шт.

143

162409A1

WASHER

1шт.

144

KHN2061

WASHER

1шт.

145

KHN12681B1

STAY

1шт.

146

KHN12690

COLLAR

3шт.

147

KHN12700

COLLAR

6шт.

148

152718A1

BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9

6шт.

153

KHN10940

RUBBER PAD

2шт.

154

KHN13510B1

COVER

2шт.

155

KHN13540

BOLT,Spcl

8шт.
