Запчасти Case CX250C (08-008[00]) - HYDRAULIC CIRCUIT - BOOM CYLINDER (08) - HYDRAULICS

1

155210A1

O-RING

1шт.

2

KBJ15380

HYD TUBE

1шт.

3

862-10030

HEX SOC SCREW,M10 x 30mm, Cl 12.9

4шт.

4

155211A1

O-RING

1шт.

5

KBJ15390

HYD TUBE

1шт.

6

862-10035

HEX SOC SCREW,M10 x 35mm, Cl 12.9

4шт.

7

KRJ10900

SUPPORT

1шт.

8

166352A1

BOLT

M12 x 30

2шт.

9

152085A1

COLLAR

1шт.

10

167183A1

BOLT,Sems, M12 x 60mm, Cl 10.9

1шт.

11

KRJ11331

HYDRAULIC HOSE

4шт.

12

KHJ1360

O-RING,0.07" Thk x 0.739" ID

4шт.
