(10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT

Запчасти Case CX235C SR (10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT (10) - ENGINE

Схема запчастей Case CX235C SR - (10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT (10) - ENGINE
6
17
12
27
11
10
3
10
9
16
15
9
8
14
10
11
10
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KRH15000

ENGINE

NSS

1шт.

3

KRH15030

ECU

1шт.

3

KRH15030R

REMAN ELECT CONTROL

CX235C SR CRAWLER EXCAVATOR - TIER 4 (NA) (3/12-)

1шт.

3

KRH15030C

CORE-ELECTRONIC CONT

Return Number

1шт.

6

NSS

NOT SOLD SEPARAT

Harness, Wire, Incl in 1

1шт.

8

NSS

NOT SOLD SEPARAT

Filter, Incl in 1

1шт.

9

KHH13380

JOINT

2шт.

10

KHH12610

PACKING RING

4шт.

11

KHH12600

SCREW

2шт.

12

NSS

NOT SOLD SEPARAT

Relay, Incl in 1

1шт.

13

NSS

NOT SOLD SEPARAT

Sensor, Incl in 1

1шт.

14

KHH0536

SENSOR

1шт.

15

NSS

NOT SOLD SEPARAT

Sensor, Incl in 1

1шт.

16

KRH13650

ECU

1шт.

16

84389447R

REMAN ELECT CONTROL

CX235C SR CRAWLER EXCAVATOR - TIER 4 (NA) (3/12-), Reman for New PN KRH13650

1шт.

16

84389447C

CORE-ELECTRONIC CONT

Return Number

1шт.

17

NSS

NOT SOLD SEPARAT

Resistor, Incl in 1

1шт.

27

84273157

FUEL FILTER

1шт.
