(10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT

Запчасти Case CX210C LR (10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT (10) - ENGINE

Схема запчастей Case CX210C LR - (10.001.02[02]) - ENGINE MOUNTING - ENGINE - OIL CIRCUIT (10) - ENGINE
9
11
17
10
14
8
3
11
12
15
9
10
10
6
10
27
16
13
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

3

KRH15030

ECU

1шт.

3

KRH15030R

REMAN ELECT CONTROL

CX210C LR CRAWLER EXCAVATOR - TIER 4 (NA) (4/12-)

1шт.

3

KRH15030C

CORE-ELECTRONIC CONT

Return Number

1шт.

6

NSS

NOT SOLD SEPARAT

Harness, Incl in Upper Assy

1шт.

8

NSS

NOT SOLD SEPARAT

Filter, Incl in Upper Assy

1шт.

9

KHH13380

JOINT

2шт.

10

KHH12610

PACKING RING

4шт.

11

KHH12600

SCREW

2шт.

12

NSS

NOT SOLD SEPARAT

Relay, Starter, Incl in Upper Assy

1шт.

13

NSS

NOT SOLD SEPARAT

Relay, Spl

1шт.

14

KHH0536

SENSOR

1шт.

15

NSS

NOT SOLD SEPARAT

Sensor, Incl in Upper Assy

1шт.

16

KRH13650

ECU

1шт.

16

84389447R

REMAN ELECT CONTROL

CX210C LR CRAWLER EXCAVATOR - TIER 4 (NA) (4/12-), Reman for New PN KRH13650

1шт.

16

84389447C

CORE-ELECTRONIC CONT

Return Number

1шт.

17

NSS

NOT SOLD SEPARAT

Resistor, Incl in Upper Assy

1шт.

27

84273157

FUEL FILTER

1шт.
