Запчасти Case CX210C LC (35.310.05) - HYDRAULIC CIRCUIT - PLUG, BLANK-OFF - OPTIONAL (35) - HYDRAULIC SYSTEMS

1

159497A1

TEE

Inc. 2

2шт.

2

154467A1

O-RING,10.8mm ID x 2.4mm Width

1шт.

3

150860A1

COLLAR

3шт.

4

840-168

SCREW,Pan, M6 x 1 x 8mm, Cl 4.8

M6 x 8

3шт.

5

150496A1

MOUNTING CLIP

250 mm

3шт.

6

KHR28600

WIRE HARNESS

1шт.

7

150860A1

COLLAR

4шт.

8

840-168

SCREW,Pan, M6 x 1 x 8mm, Cl 4.8

M6 x 8

4шт.

9

150496A1

MOUNTING CLIP

250 mm

4шт.

10

158962A1

CLIP

4шт.

11

166345A1

BOLT

M8 x 16

4шт.

12

KHJ15060

CAP

4шт.

13

KHJ15080

CAP

1шт.

14

KHJ23010

TEE

1шт.
