Запчасти Case CX330 (03-07) - FUEL INJECTION PUMP (03) - FUEL SYSTEM

.

6TAA-8304 EMISSIONS CERTIFIED ENGINE

1шт.

J4025319

REPAIR KIT

Accumulator; Inc. 1 - 6, 9 - 42

1шт.

JR4025319

REMAN-ACCUMULATOR

Remanufactured

1шт.

JC4025319

CORE-ACCUMULATOR

Return Part Number

1шт.

J4025130

KIT

Pressure Sensing; Incl. 41, 42

1шт.

A77928

HOUSING

Cam Housingmetc; Inc. 7 - 8

1шт.

1

NSS

NOT SOLD SEPARAT

Body

1шт.

2

NSS

NOT SOLD SEPARAT

Valve, Solenoid

2шт.

3

NSS

NOT SOLD SEPARAT

Tappet

2шт.

4

NSS

NOT SOLD SEPARAT

Seal

2шт.

5

NSS

NOT SOLD SEPARAT

Plunger

2шт.

6

NSS

NOT SOLD SEPARAT

Seal

2шт.

7

NSS

NOT SOLD SEPARAT

Retainer

2шт.

8

NSS

NOT SOLD SEPARAT

Spring

2шт.

9

NSS

NOT SOLD SEPARAT

Retainer

2шт.

10

NSS

NOT SOLD SEPARAT

Plunger

2шт.

11

NSS

NOT SOLD SEPARAT

Spring

2шт.

12

NSS

NOT SOLD SEPARAT

Shim

2шт.

13

NSS

NOT SOLD SEPARAT

Seat

2шт.

14

NSS

NOT SOLD SEPARAT

Plug

2шт.

16

J4010636

SEAL

1шт.

17

J867640

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

1шт.

18

J347925

ELEC CONNECTOR

Incl. 19

1шт.

19

NSS

NOT SOLD SEPARAT

Screen

1шт.

20

J867043

SEAL,1.78mm Thk x 10.82mm ID

1шт.

21

J417161

HARNESS

Incl. 22

1шт.

22

J417095

CABLE CLIP

1шт.

23

NSS

NOT SOLD SEPARAT

Bolt

1шт.

24

J331002

FLANGE BOLT,Hex, M10 x 1.5 x 80mm, Gr 10.9

4шт.

J4010544

ADJUSTER

Incl. 35 - 39

1шт.

35

NSS

NOT SOLD SEPARAT

Adapter

1шт.

36

NSS

NOT SOLD SEPARAT

Guide

1шт.

37

NSS

NOT SOLD SEPARAT

Spring

1шт.

38

NSS

NOT SOLD SEPARAT

Seat, Valve

1шт.

39

J4010545

WASHER

1шт.

41

NSS

NOT SOLD SEPARAT

Sensor

1шт.

42

J4076375

SEALING WASHER,6mm ID x 9.5mm OD x 1.9mm Thk

1шт.
