Запчасти Case CX225SR (09-05) - CAB FRONT WIPER (09) - CHASSIS/ATTACHMENTS

45

KAN2665

LOCK

1шт.

KHN18630

WINDOW

Incl. 45 - 53 and 31 - 64 in Fig. 09-04

1шт.

46

KAN1514

SCREW

8шт.

47

KAN2666

BOLT,Spcl

1шт.

48

KAN2667

WASHER

1шт.

49

KAN2668

WASHER

1шт.

50

KHN3118

LOCK

1шт.

51

KAN2786

SWITCH

1шт.

52

KAN2626

SCREW

2шт.

53

KAN2670

HANDLE

1шт.

54

KHN3119

SCREW,Spcl

2шт.

55

KHN3156

PIN

2шт.

56

KAN2608

NUT

2шт.

57

KHN3120

FOAM INSULATION

1шт.

65

KHN3036

WIRE HARNESS

1шт.

66

KHN3037

GROMMET

2шт.

67

KHN18540

HARNESS

HARNESS, WIRE

1шт.

68

KHN18550

WIPER MOTOR

WIPER MOTOR

1шт.

69

KAN2745

CLIP

CLIP

3шт.

70

KHN18600

WIPER ARM

1шт.

71

KHN18610

WINDSHIELD WIPER

1шт.

72

KAN2608

NUT

1шт.

73

KHN3144

SPACER

1шт.

74

KHN3145

SEAL

1шт.

75

KHN3146

WASHER

1шт.

76

KHN3147

SPECIAL NUT

1шт.

77

KHN3148

CAP

1шт.

78

KHN3149

SEAL

2шт.

79

KAN2725

NOZZLE

1шт.

80

KHN3042

TUBE

1шт.

83

KHN3043

ANTENNA

1шт.

84

KHN3044

SCREW,Spcl

1шт.

85

KHN3045

SCREW,Spcl

1шт.

86

KHN3046

GLASS

1шт.

87

KHN3047

SPACER

2шт.

88

KHN3054

SCREW

4шт.

89

KHN3049

STOP

1шт.

90

KHN3050

STOP

1шт.

91

KHN3051

SCREW,Spcl

8шт.

92

KHN3052

RUBBER SEAL

1шт.

93

KHN3053

SPACER

2шт.

94

KHN3054

SCREW

4шт.

95

KHN3055

STOP

2шт.

96

KHN3056

RUBBER SEAL

1шт.

97

KHN3057

GLASS

Rear (kickout) Window

1шт.

98

KHN3058

SEAL, GLASS

1шт.

166

KAN2786

SWITCH

CONNECTOR

1шт.

167

KHN3443

WASHER

4шт.

168

KHN3444

COLLAR

4шт.

169

KHN18570

COVER

COVER

1шт.

170

KHN18580

PLATE

PLATE

1шт.

171

KHN18590

PROTECTOR

PROTECTOR

1шт.

172

KHN19400

PLUG

PLUG

1шт.

173

KHN19420

FIXING STRIP

BAND HARNESS

1шт.

179

KHR20970

SUPPRESSOR

2шт.
