Запчасти Case 125B (9-038) - HAND CONTROL VALVE CONSOLES, P.I.N. 74871 THROUGH 74963 (09) - CHASSIS

1

REF

INSTRUCTION

SEAT ASSEMBLY - operator's, parts list Figures 8-30 or 8-32

1шт.

P5242763

CASE

HOUSING ASSEMBLY - console, right-hand, Includes: Ref. 2 - 4

1шт.

2

NSS

NOT SOLD SEPARAT

HOUSING - right-hand console

1шт.

3

P35001

WASHER

- flat, 6 mm

1шт.

4

120100

BOLT,M6 x 20mm, Cl 8.8

1шт.

P5242764

CASE

HOUSING ASSEMBLY - console, left-hand

1шт.

5

P1737419

PLUG

- plastic, left-hand console, Includes: Ref. 7 - 9

2шт.

6

P1737425

PLASTIC PLUG

PLUG - plastic, left-hand console, Includes: Ref. 7 - 9

2шт.

7

NSS

NOT SOLD SEPARAT

HOUSING - left-hand console

1шт.

8

P35001

WASHER

- flat, 6 mm

1шт.

9

120100

BOLT,M6 x 20mm, Cl 8.8

1шт.

10

814-6025

BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd

- hex head, 6 mm - 1 x 25 mm, plated

8шт.

11

P35001

WASHER

- flat, 6 mm

8шт.

12

P152069

HANDLE

- half, Includes: Ref. 13

4шт.

13

825-1106

NUT,Hex, M6, Cl 8

- hex, 6 mm

4шт.

14

P32549

SCREW

- handle, lower, 6 mm x 16 mm

4шт.

15

P34107

NUT - hex, 4 mm

4шт.

16

P32530

SCREW

- handle, upper, 4 mm x 10 mm

4шт.

17

P1027977

PIN

- pivot

2шт.

18

P33808

SCREW

BOLT - hex head, 6 mm x 30 mm

2шт.

19

P3528799

WASHER

SPACER - 4 mm, thick, bolt

8шт.

20

P1436931

CYLINDER ASSY.

ABSORBER - shock, left-hand console

1шт.

21

P827645

PIN

- shock absorber

2шт.

22

P35001

WASHER

- flat, 6 mm

4шт.

23

P35510

SPLIT PIN

PIN - cotter, 2 mm x 20 mm

4шт.

24

P152075

CONE

RETAINER - latch

1шт.

25

P34611

WASHER

- flat, 10 mm, retainer mounting

1шт.

26

P34598

SAFETY NUT

NUT - hex, self-locking, 10 mm

1шт.

27

P1352035

LOCK ASSY

LATCH - left-hand console

1шт.

28

P323672

HOOD

PLATE - latch mounting, lower

1шт.

29

P733035

SCREW

BOLT - hex head, 6 mm x 35 mm

4шт.

30

P3528799

WASHER

SPACER - 4 mm thick, bolt

4шт.

31

P852064

HANDLE

- latch

1шт.

32

P1027968

CLEVIS

CONNECTOR - at handle

1шт.

33

P134596

SAFETY NUT

NUT - hex, self-locking, 8 mm

1шт.

34

P35002

WASHER

- flat, 8 mm

2шт.

35

P741463

STOP

BUMPER - left-hand console

1шт.

36

P3528794

WASHER

SPACER - bumper mounting, 6 mm thick

1шт.

37

P34113

NUT

- hex, 8 mm

1шт.
