Запчасти Case 125B (8-168) - CRANING VALVE HYDRAULIC CONTROL CIRCUIT, P.I.N. 21807 THRU 21868, 26801 AND AFTER (08) - HYDRAULICS

1

REF

INSTRUCTION

BLOCK ASSEMBLY - manifold, parts list Figure 8-264

2шт.

2

J532918

SCREW,Hex Skt, M12 x 40mm, Cl 10.9

8шт.

3

P6731988

HOSE

- 63" (1600 mm) long, manifold block out

2шт.

4

P3231995

HOSE

- 39-3/8" (1000 mm) long, tee to return tube

1шт.

5

P37234

TEE

- manifold block return circuit

1шт.

6

P50458

BLANK-OFF PLUG

CAP - hydraulic fitting, DN27

1шт.

7

P3037504

UNION

ADAPTER - straight

1шт.

P945293

WASHER, SEALING

O-RING - adapter

1шт.

8

REF

INSTRUCTION

HOSE - 63" (1600 mm) long, control circuit, cut from P1103640

1шт.

9

P4037588

END FITTING

ADAPTER - straight, control circuit hose

2шт.

10

P4037590

END FITTING

ADAPTER - 90 degree, control circuit hose

2шт.

11

P2337593

FITTING

ADAPTER - long, to manifold block

1шт.

P945293

WASHER, SEALING

O-RING - adapter

1шт.

12

P37247

TEE

- manifold block return circuit

1шт.

13

P4431991

HOSE

- 19-3/4" (500 mm) long, manifold, Serial Range: block-tee

1шт.

14

P2337592

UNION

ADAPTER - straight, hose to manifold block

1шт.

P945293

WASHER, SEALING

O-RING - adapter

1шт.

15

REF

INSTRUCTION

HOSE - 124-3/16" (3500 mm) long, control circuit, cut from P1103640

1шт.

16

NSS

NOT SOLD SEPARAT

HYDRAULIC CIRCUIT ASSEMBLY - parts list Figure 8-148

1шт.

17

NSS

NOT SOLD SEPARAT

HYDRAULIC CIRCUIT ASSEMBLY - parts list Figures 8-144 and 8-146

1шт.

18

NSS

NOT SOLD SEPARAT

HYDRAULIC CIRCUIT ASSEMBLY - parts list Figure 8-100 Ref. 11

1шт.
