Запчасти Case 170B (4-74) - TURNTABLE ELECTRICAL HARNESS, HARNESS CONNECTIONS TO ELECTRICAL BOX, P.I.N. 74425 THRU 74456 (04) - ELECTRICAL SYSTEMS

1

REF

INSTRUCTION

HARNESS - at turntable, see Figure 4-72, Refs. 4,8,10,14,16 and 21

1шт.

2

REF

INSTRUCTION

ELECTRICAL BOX - excavator, see Figures 4-86 and 4-88

1шт.

3

P9247222

ELECTRICAL WIRE

WIRE - 12-3/4" (350 mm) long, connector, electrical box

1шт.

4

P9547220

ELECTRICAL WIRE

WIRE - 21-5/8" (550 mm) long, 21-5/8" (550 mm) long, connector, electrical box

1шт.

5

P9547225

ELECTRICAL WIRE

WIRE - 19-5/8" (500 mm) long, connector, electrical box

1шт.

6

P8647281

ELECTRICAL WIRE

WIRE - 23-5/8" (600 mm) long, connector, electrical box

1шт.

7

P9547221

ELECTRICAL WIRE

WIRE - 21-5/8" (550 mm) long, connector, electrical box

1шт.

8

P9547226

ELECTRICAL WIRE

WIRE - 19-5/8" (500 mm) long, connector, electrical box

1шт.

9

P9547226

ELECTRICAL WIRE

WIRE - 3-15/16" (100 mm) long, connector, electrical box

1шт.

10

P9247221

ELECTRICAL WIRE

WIRE - 13-3/4" (350 mm) long, connector, electrical box

1шт.
