Запчасти Case 170B (2-18) - EXHAUST SYSTEM AND ENGINE AIR COOLING ADAPTING PARTS, P.I.N. 74341 THRU 74424 (02) - ENGINE

1

P1540226

FUEL TANK

TANK ASSEMBLY - fuel, parts list Figure 3-30

1шт.

2

P2254804

DEFLECTOR

SHIELD - heat, muffler

1шт.

3

814-10045

BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8

- hex head, 10 mm - 1.5 x 45 mm, plated

4шт.

4

P3528795

WASHER

SPACER - shield bolt

4шт.

5

P3141450

MUFFLER

- engine

1шт.

6

P1246096

SEAL

GASKET -, Serial Range: muffler-engine

1шт.

7

814-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd

4шт.

8

P4328796

WASHER

SPACER - muffler bolt

4шт.

9

P2750152

PIPE, EXHAUST SYSTEM

PIPE - engine exhaust, includes clamp

1шт.

10

P233830

SCREW

BOLT - exhaust pipe

1шт.

11

P6522798

PLATE

SPACER - exhaust pipe bolt

2шт.

12

P34113E

NUT,M8, Cl 8

- hex,exhaust pipe bolt

1шт.

13

P4127154

PROTECTOR

SHIELD - heat, exhaust pipe

1шт.

14

814-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd

- hex head, 8 mm - 1.25 x 30 mm, plated

3шт.

15

P3528794

WASHER

SPACER - exhaust pipe bolt

6шт.

16

P134596

SAFETY NUT

NUT - hex, exhaust pipe bolt

3шт.

17

P4127143

SUPPORT

BRACKET - support, Serial Range: muffler-engine

1шт.

18

814-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd

- hex head, 8 mm - 1.25 x 30 mm, plated

2шт.

19

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

BOLT, , Bracket to Engine Hex, M8 x 25, 8.8

2шт.

20

P3528794

WASHER

SPACER - bracket bolt

6шт.

21

P134596

SAFETY NUT

NUT - hex, bracket bolt

2шт.

22

REF

INSTRUCTION

HOSE - 70-7/8" (1800 mm) long, crankcase breather, cut from P31901

1шт.

23

P36998

COLLAR CLAMP

CLAMP - hose

2шт.

24

P9428110

ENGINE VENT SLEEVE

ADAPTER -, Serial Range: flange-engine

1шт.

25

P1446073

SEAL, RUBBER

FLANGE - rubber, engine air cooling

1шт.

26

P733035

SCREW

BOLT - flange and, Serial Range: adapter-engine

12шт.

27

P3528799

WASHER

SPACER - flange and adapter bolt

24шт.

28

P234513

SAFETY NUT

NUT - hex, flange and adapter bolt

12шт.
