Запчасти Case 220B (4-54) - SWING BRAKE ELECTRICAL HARNESS, P.I.N. 74441 THROUGH 74597, P.I.N. 03201 AND AFTER (04) - ELECTRICAL SYSTEMS

1

REF

INSTRUCTION

BOX ASSEMBLY - electrical, printed circuit, see Figures 4-56 through 4-68 for correct electrical box

1шт.

2

P141439

NUT

- lock, bushing

1шт.

P8647283

CABLE

HARNESS - swing brake

1шт.

3

NSS

NOT SOLD SEPARAT

HARNESS - swing brake

1шт.

4

P141431

GLAND

BUSHING - harness locking

1шт.

5

P136922

CLAMP

STRAP - tie, harness

1шт.

6

REF

INSTRUCTION

VALVE ASSEMBLY - control, solenoid, 13 bar, see Figures 8-150 and 8-152 for correct valve and component parts

1шт.

7

P1843371

SHIN

VALVE ASSEMBLY - control, solenoid, 35 bar, see Figure 8-148 for valve components and correct manifold block

2шт.
