Артикул
Название
Примечание
Количество
1
614-12040
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
- hex, full threads, 12 - 1.75 x 40 mm, engine mount to turntable
8шт.
2
P3528793
WASHER
SPACER -, Serial Range: bolt-mount
8шт.
3
P1541482
SUPPORT
MOUNT - engine, flexible
2шт.
4
P6228190
FOOT
BRACKET - engine mount, front
2шт.
5
814-16090
BOLT,Hex, M16 x 2 x 90mm, Cl 8.8
Bracket to mount (Replaces bolt P33855) Hex, M16 x 90, 8.8
2шт.
6
P3528790
WASHER
SPACER - bolt, Serial Range: bracket-mount
2шт.
7
814-12060
BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8
Bracket to engine Hex, M12 x 60, 8.8
8шт.
8
P3528793
WASHER
SPACER - bolt, Serial Range: bracket-engine
8шт.
9
614-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
Full Thd, Engine mount to turntable Hex, M10 x 30, 8.8, Serial Range: 74441-74597
8шт.
9
614-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
Full Thd, Engine mount to turntable Hex, M10 x 30, 8.8, Serial Range: 03201-03213
8шт.
9
814-10055
BOLT,Hex, M10 x 1.5 x 55mm, Cl 8.8
- hex, 10 - 1.5 x 55 mm, Engine mount to turntable (Replaces bolt P133869), Start Serial: 03214
8шт.
10
P3528795
WASHER
SPACER - bolt to mount 74441 to 74597
8шт.
10
P3528795
WASHER
SPACER - bolt to mount 03201 to 03213
8шт.
10
P3528795
WASHER
SPACER - bolt to mount, Start Serial: 03214
16шт.
11
P741473
SUPPORT
MOUNT - engine, flexible
2шт.
12
P933819
SCREW
BOLT -, Serial Range: bracket-engine
8шт.
13
P3528793
WASHER
SPACER -, Serial Range: bolt-mount
10шт.
14
P8628167
FOOT
BRACKET - engine mount, rear, left-hand
1шт.
15
P8628166
FOOT
BRACKET - engine mount, rear, right-hand
1шт.
16
614-12100
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8, Full Thd
- , Bracket to mount (Replaces bolt P32678) Hex, M12 x 100, 8.8, Full Thd
2шт.
17
832-10410
NUT,M10 x 1.5, Cl 8
NUT, LOCK, , Mount to turntable (Replaces nut P34598) M10 x 1.5, Cl 8, Start Serial: 03214
8шт.
Выбрано товаров: 21
