Запчасти Case 688C (9F-18) - ARM 2,10M (05.1) - UPPERSTRUCTURE CHASSIS/ATTACHMENTS

1

ARM dipper Consist Of : 2-5, See To Sales Department

1шт.

2

N1127863

SHAFT LOCK

2шт.

3

B1528673

BUSHING

60 x 75 x 55

2шт.

4

C4628706

BUSHING

60 x 75 x 58

2шт.

5

M5428747

BUSHING

2шт.

6

C130918

PIN

60

1шт.

7

U50388

PIN

Dia 60

1шт.

8

C36020

SPLIT PIN/SAFETY PIN

1шт.

9

R151309

SEAL,60mm ID x 75mm OD x 8mm Thk

6шт.

10

V151313

GASKET

4шт.

11

H3145326

WASHER,61mm ID x 130mm OD x 2mm Thk

61 x 140 x 2

2шт.

12

W45836

LUBE NIPPLE,1/8"-27 NPT

6шт.

13

L145347

WASHER,61mm ID x 110mm OD x 2mm Thk

61 x 110 x 2

2шт.
