Запчасти Case 688C (9D-10) - CAB FLOOR LOWER LOCK (05.1) - UPPERSTRUCTURE CHASSIS/ATTACHMENTS

1

H3126328

HOOD

SUPPORT

1шт.

2

J1133839

SCREW

M10 x 45 x 45

2шт.

3

N4328796

WASHER

"10.25 x 7 x 20"

4шт.

4

G34598

SAFETY NUT

M10

2шт.

5

W7128272

SPOOL

LOCK

1шт.

6

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

2шт.

7

N4328796

WASHER

"10.25 x 7 x 20"

2шт.

8

S6522793

PLATE

2шт.

9

Z4441460

FOAM

INSULATION Replace : F4241458

1шт.
