Запчасти Case 688 (9D-18) - ENGINE THROTTLE CONTROL (09) - CHASSIS

1

P7128255

SUPPORT

BRACKET - support, throttle control

1шт.

2

P32621

SCREW

BOLT - hex, 6 mm x 16 mm

2шт.

3

P3528799

WASHER

SPACER - bolt, 4 mm thick

2шт.

4

P1634573

NUT

- hex, self-locking, 6 mm

2шт.

5

P5242767

LEVER

HANDLE - throttle control

1шт.

6

P29298

SELF LUB RING

BUSHING - handle

1шт.

7

P1245218

WASHER

SHIM, Serial Range: --bracket

1шт.

8

P34906

RUBBER WASHER

WASHER - spring type

2шт.

9

P35005

WASHER

- flat, 14 mm

2шт.

10

P34546

NUT

- hex, 14 mm

1шт.

11

P34168

NUT

- hex, 14 mm

1шт.

12

P152055

BALL KNOB

KNOB - handle

1шт.

13

P1751525

DECAL

- travel way

1шт.

14

P2146214

CLEVIS

FORK ASSEMBLY - throttle control

2шт.

15

P4831337

CABLE

ASSEMBLY - throttle control

1шт.

16

P2425994

STOP LOCK

BRACKET - throttle cable at engine

1шт.

17

86977786

BOLT,Hex, M6 x 1 x 25mm, Cl 8.8

Hex, M6 x 25, 8.8, Full Thd

2шт.

18

P35001

WASHER

SPACER - bolt, 4 mm thick (Replaces P3528799)

4шт.

19

P234513

SAFETY NUT

NUT - hex, self-locking, 6 mm

2шт.
