Запчасти Case 688 (8B-32) - REGULATOR, PILOT VALVE (08) - HYDRAULICS

P4543544

PUMP

HYDRAULIC PUMP ASSEMBLY - high pressure, Includes: Ref. 1 - 29, Serial Range: 11601-XXXXX

1шт.

P4543564

PUMP

HYDRAULIC PUMP ASSEMBLY - high pressure, Includes: Ref. 1 - 29, Start Serial: XXXXX

1шт.

P3843602

GOVERNOR

REGULATOR - hydraulic pump, Includes: Ref. 1 - 29

1шт.

P3843605

PILOT VALVE

VALVE ASSEMBLY - pilot valve

1шт.

1

NSS

NOT SOLD SEPARAT

BODY - pilot valve

1шт.

2

NSS

NOT SOLD SEPARAT

LINER - spool

1шт.

3

NSS

NOT SOLD SEPARAT

SPOOL - pilot valve

1шт.

4

P5240344

CAP

BODY - load sensing valve

1шт.

5

P3628837

GUIDE

SEAT - spring, large

1шт.

6

P1038269

SPRING

- pressure, load sensing valve

1шт.

7

P1038247

SPRING

- load sensing valve

1шт.

8

P4743381

SEAT

LINER - orifice

1шт.

9

P4743382

SEAT

LINER - orifice

1шт.

10

P3628838

BUSHING

SLEEVE - body

2шт.

11

P4743383

VALVE POPPET

PLUNGER - flow control

2шт.

12

P1038270

SPRING

- flow control

2шт.

13

P3628839

GUIDE

SEAT - spring, flow control

2шт.

14

P5240345

CAP

BODY - plunger

2шт.

15

P4837513

FITTING

ADAPTER - body

2шт.

16

P3628841

GUIDE

SEAT - spring, small

1шт.

17

P32892

SCREW

- adjusting screw, load sensing valve

1шт.

18

P3743284

JET

ORIFICE - pilot valve

1шт.

19

P31002

BALL

- flow control valve

1шт.

20

P2930489

O-RING

- body, load sensing valve

1шт.

21

P3034502

NUT

- adjusting screw, load sensing valve

3шт.

22

P32893

SCREW

- adjusting screw

2шт.

23

P2930431

O-RING

- body, flow control valve

2шт.

24

P2930481

GASKET,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

O-RING - body to regulator body

3шт.

25

P3337447

PLUG

- body, large

1шт.

26

P3337449

PLUG

- body, small

1шт.

27

P3743284

JET

ORIFICE - flow control valve

2шт.

28

P232914

SCREW

BOLT - hex socket head, M6 x 55 mm

4шт.

29

P1245282

GASKET

BACKUP RING - seal

1шт.
