Запчасти Case 888 (8F-04) - TURNTABLE LEVELER HYD. CNTRL. CIRCUIT, MANIFOLD TO LEVELER FOOT CNTRL. VALVE, P.I.N. 106801 & AFTER (08) - HYDRAULICS

1

P4343360

BLOCK ASSY.

VALVE ASSEMBLY - foot control, parts list Fig. 8D-14

1шт.

2

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

BOLT, Hex, M8 x 25, 8.8

4шт.

3

P1334571

NUT

- hex, cage type, 8 mm

4шт.

4

P3237530

UNION

ADAPTER ASSEMBLY - straight

5шт.

P7046042

SEAL

- adapter

1шт.

5

P3237581

UNION

ADAPTER ASSEMBLY - straight

1шт.

P7046042

SEAL

- adapter

1шт.

6

P5431984

HOSE

- control, at manifold block, 1000 mm (39-3/8 inch) long

2шт.

7

P5431954

HOSE

- control, to swivel, 1400 mm (55-1/8 inch) long

2шт.

8

P2036942

SUPPORT

RETAINER - control circuit hoses

5шт.

9

P51946

CLAMP

STRAP - tie, circuit hose, 257 mm (10-1/8 inch) long

1шт.

10

P3037430

PLASTIC PLUG

PLUG - plastic, foot pedal, if used

2шт.

11

P2036902

CLASP

CLIP - retainer, 3 - 6 mm (1/8 - 1/4 inch) range

1шт.

12

PP2036939

CLASP

RETAINER - tie strap

1шт.
