Запчасти Case 888 (2-40) - CYLINDER HEAD COVER, 6T-590 DIESEL ENGINE (02) - ENGINE

1

REF

INSTRUCTION

HEAD ASSEMBLY - cylinder, parts list Fig. 2-42

1шт.

2

J928404

COVER

- rocker (Replaces cover J902604)

6шт.

3

J902666

GASKET

SEAL - rocker cover

6шт.

4

J928406

ISOLATOR

- noise, rocker arm (Replaces O-rings J901837 and J910824)

6шт.

5

J907049

BOLT,Hex

- special, 8 mm - 1.25 x 21 mm

6шт.

8

J283335

GASKET,2.32mm Thk

- head, standard, one notch (Replaces gaskets J907057 and J917358)

1шт.

8

J918306

GASKET

- head, 0.23 mm overthick, two notch (Replaces gaskets J907058 and J917359)

1шт.

8

J921398

GASKET

- head, 0.50 mm overthick, three notch (Replaces gaskets J907059 and J917360)

1шт.

9

J908118

BRACKET

- lifting, rear

1шт.

10

813-12025

BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd

- hex, 12 mm - 1.75 x 25 mm

2шт.

12

J903757

BRACKET

- lifting, front, thermostat and housing

1шт.

13

J920020

GASKET

- housing (Replaces gasket J903301), thermostat

1шт.

14

J917324

THERMOSTAT

- water, 95 degree Celsius, order A77736 for service (Replaces thermostat J912587), housing

1шт.

15

J914409

HOUSING

- thermostat (Replaces housing J903756)

1шт.

18

845-8070

BOLT,Hvy Hex, M8 x 70mm, Cl 8.8

- heavy hex flange, 8 mm - 1.25 x 70 mm, Thermostat and housing

2шт.

19

845-8035

BOLT,Hvy Hex, M8 x 35mm, Cl 8.8

- heavy hex flange, 8 mm - 1.25 x 35mm, Thermostat and housing

1шт.

20

J923387

SUPPORT

- alternator mounting (Replaces support J910713), thermostat and housing

1шт.

21

613-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

- hex, 8 mm x 25 mm, grade 10.9, thermostat and housing

3шт.
