Запчасти Case 880D (114) - FINAL DRIVE TRANSMISSION MOUNTING (04) - UNDERCARRIAGE

1

REF

INSTRUCTION

TRANSMISSION ASSEMBLY - see Figure 119 for the correct assembly and components

2шт.

2

S514516

BRACKET

- transmission mounting, right-hand

1шт.

3

S514517

BRACKET

- transmission mounting, left-hand

1шт.

4

113-709

BOLT,Hex, 3/4" - 10 x 1-1/2", Gr 5

Use with Loctite 271 red, see below Hex, 3/4"-10 x 1 1/2", G5

8шт.

5

S238925

LINKAGE

LINK - bracket to track frame

4шт.

6

113-926

BOLT,Hex, 1" - 8 x 4", Gr 5

- hex head, 1" - 8 NC x 4", plated, upper

2шт.

7

113-933

BOLT,Hex, 1" - 8 x 3-3/4", Gr 5

- hex head, 1" - 8 NC x 3-3/4", plated, lower

2шт.

8

195-53

WASHER,1" x 2" x .134"

- flat, 1", plated, used for shimming

1шт.

9

131-82

NUT,1"-8

NUT - hex, self-locking, 1" - 8 NC

4шт.

B17423

LOCTITE

- 271 red, 50cc bottle

1шт.
